| Specifications | Value |
|---|---|
| No. | 964739 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
Description
【 Premium Recommendation 】 A second-hand XCMG XE135 excavator from 2020, with an actual watch time of only 6,000 hours, in excellent condition and offering an extremely high cost performance! Since its commissioning, this excavator has maintained a good maintenance condition, ensuring its excellent performance and long service life. The XCMG XE135 is equipped with a high-performance engine, which is powerful and has good fuel economy. It can handle both plain and mountainous operations with ease, ensuring high work efficiency. In addition, this model adopts an advanced hydraulic system design, which is flexible and precise to operate. Whether it is excavation, loading or crushing operations, it can demonstrate excellent controllability and stability. The cab is spacious and comfortable with a wide field of vision, which greatly enhances the driver's operating experience. The whole machine has a sturdy and durable structure. Key components are all made of high-quality materials, which have strong wear resistance and effectively reduce maintenance costs. For those users who pursue high cost performance and stable performance, this XCMG XE135 is undoubtedly an ideal choice. In terms of price, we promise it is absolutely fair and reasonabl
