| Specifications | Value |
|---|---|
| No. | 965970 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
Description
【 Premium Recommendation 】 XCMG XE60 Mini Excavator of 2021 This XCMG XE60 mini excavator was purchased in 2021 and has only been in use for 1,500 hours. It is in excellent condition and has stable performance, making it an ideal choice for your construction work. This device is equipped with a high-quality Yanmar 4TNV98-ZT engine, which is powerful and fuel-efficient. Its maximum power can reach 36.4kW at 2200rpm, ensuring efficient operation even in harsh working environments. Meanwhile, its unique cooling system design ensures excellent heat dissipation during long-term operation, effectively extending the engine's lifespan. In terms of the hydraulic system, this machine is equipped with an advanced load-sensitive control system, which responds quickly and operates precisely. It can handle both excavation and loading operations with ease. In addition, multiple working modes have been specially set up for users to choose from, which can be flexibly adjusted according to actual needs to achieve the best balance between work efficiency and fuel economy. The whole machine has a compact structure and high flexibility, making it suitable for precise operations in various confined Spaces. The sturdy and durable chassis design ensures ex
