2016 XCMG XE60

1/9
Used XCMG XE60 Excavator 2016 Model / 1
Used XCMG XE60 Excavator 2016 Model / 2
Used XCMG XE60 Excavator 2016 Model / 3
Used XCMG XE60 Excavator 2016 Model / 4
Used XCMG XE60 Excavator 2016 Model / 5
Used XCMG XE60 Excavator 2016 Model / 6
Used XCMG XE60 Excavator 2016 Model / 7
Used XCMG XE60 Excavator 2016 Model / 8
Used XCMG XE60 Excavator 2016 Model / 9

Product Description

XCMG XE60 second-hand excavator, meeting the National III emission standards, with an estimated cumulative working time of around 5,000 hours. It is purely for personal use and has no rental or commercial operation records. This device is equipped with a highly efficient and reliable diesel engine, model Yanmar 4TNV98-ZZ, with a rated power of 36.2 kilowatts, ensuring strong power output and excellent fuel economy. In terms of the hydraulic system, it is equipped with a high-quality main pump and hydraulic motor combination, ensuring the smoothness and response speed of the entire machine's operation. Whether it is excavation, loading or crushing operations, it can handle them with ease. The overall appearance of the vehicle is neat and straight, and its structural components are sturdy and durable. It has been strictly inspected and confirmed to have no structural damage at all. It is worth mentioning that if this excavator is properly maintained and key components such as the oil filter are regularly replaced, the internal cleanliness of the machinery remains high, and large parts remain dry without oil leakage. This not only extends its service life but also reduces subsequent maintenance costs. In addition, it fully complies with

SpecificationsValue
No.973237
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.973237

Brand Name:

XCMG

Model Number:

XE60

Year:

2016

Location:

Hebei China
