2015 XCMG XE60

1/6
Used XCMG XE60 Excavator 2015 Model / 1
Used XCMG XE60 Excavator 2015 Model / 2
Used XCMG XE60 Excavator 2015 Model / 3
Used XCMG XE60 Excavator 2015 Model / 4
Used XCMG XE60 Excavator 2015 Model / 5
Used XCMG XE60 Excavator 2015 Model / 6

Product Description

This second-hand XCMG XE60 excavator from 2015 has a usage record of 33,000 hours and is one of the most favored small excavators in the market. It is equipped with the high-performance Yanmar 4TNV98 engine, with a rated power of 40 kilowatts, ensuring strong power output and excellent fuel economy. In terms of the hydraulic system, this equipment is equipped with a high-quality combination of variable piston pumps and hydraulic motors, which not only ensures a rapid response operation experience but also significantly enhances work efficiency. The main advantages of this excavator lie in its compact design and flexible operability, making it highly suitable for construction operations in narrow Spaces such as urban construction sites and landscaping. Meanwhile, the robust and durable structural design enables the machine to maintain excellent stability and reliability even in harsh working environments. In addition, the cab is equipped with comfortable seats and an intuitive and easy-to-understand operation panel, which greatly enhances the operator's working comfort and safety. Overall, this XCMG XE60 excavator, with its powerful power system, efficient hydraulic configuration and excellent overall performance, has a distinct compe

SpecificationsValue
No.976969
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.976969

Brand Name:

XCMG

Model Number:

XE60

Year:

2015

Location:

Guizhou China
