Product Description
We are selling a second-hand XCMG XE135 excavator produced in 2013, with a cumulative working time of 6,000 hours. This device is equipped with an efficient and reliable engine, which is expected to be a Cummins B Series 4-cylinder turbocharged engine with a power output of approximately 75 kilowatts, ensuring strong power output and smooth operation performance. In terms of the hydraulic system, high-quality main pumps and main valves are adopted, which may include hydraulic pumps and motors of Kawasaki or Rexroth brands. These components ensure rapid response and precise control, enabling the entire machine to perform outstandingly in operations such as excavation and loading. The main advantages of XCMG XE135 excavator lie in its outstanding operational comfort and durability. The spacious cab design offers a good view and is equipped with an advanced air conditioning system, ensuring a comfortable working environment even in harsh conditions. In addition, this model also features excellent fuel economy, effectively reducing operating costs. The sturdy structural components and the key parts with strengthened treatment further enhance the overall service life of the machine. This is an ideal choice that is hard to come by for users
| Specifications | Value |
|---|---|
| No. | 977164 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
