2018 XCMG XE60

1/8
Used XCMG XE60 Excavator 2018 Model / 1
Used XCMG XE60 Excavator 2018 Model / 2
Used XCMG XE60 Excavator 2018 Model / 3
Used XCMG XE60 Excavator 2018 Model / 4
Used XCMG XE60 Excavator 2018 Model / 5
Used XCMG XE60 Excavator 2018 Model / 6
Used XCMG XE60 Excavator 2018 Model / 7
Used XCMG XE60 Excavator 2018 Model / 8

Product Description

This second-hand XCMG XE60 excavator produced in 2018 offers you a highly cost-effective choice at a price of 40,000 yuan. This device has a working record of approximately 3,500 hours, indicating that it has demonstrated excellent durability and reliability in past use. In terms of the power system, it is equipped with an efficient and energy-saving engine. Although the specific model is not provided, based on the configuration of XCMG's products in the same series, it is very likely to be a Yanmar or Kubota brand inline four-cylinder diesel engine with a rated power of approximately 40kW (possibly), which can provide sufficient power support for the entire machine. The hydraulic system is one of the key factors in measuring the performance of an excavator. This XCMG XE60 model adopts mature and reliable negative flow control technology, combined with high-performance variable piston pumps and radial piston motors, ensuring smooth operation and precise control during the working process. In addition, this model also pays special attention to the design of maintenance convenience. For instance, the open hood facilitates daily inspection and maintenance, effectively reducing long-term operating costs. Overall, this second-hand XCMG XE

SpecificationsValue
No.977268
Tonnage (tons)6
Working weight (kg)5960
Bucket capacity (m³)0.09-0.23
Boom length (mm)3000
Rod length (mm)1600
Country of originXuzhou
powerTraditional power
manufacturerMade in China
bucketbackhoe
Engine typeYanmar 4TNV94L
Rated power (kw/rpm)39.8/2200
Cooling modewater-cooling
Number of cylinders (PCS)4
Displacement (L)3.054
Ground specific pressure (Kpa)32.1
Rotation speed (rpm)9.5
Climbing ability (%)35 °
Bucket digging force (kN)42.5
Rod digging force (kN)28.5
Travel speed (km/h)4.2/2.2
Main overflow set pressure (Mpa)22
Maximum flow of main pump (l/min)2*60.5+40.3+9.9
Traveling Hydraulic Circuit (Mpa)22
Rotary Hydraulic Circuit (Mpa)23
Hydraulic crushing pipeline is standardis
Main pump typeRexroth
Pilot Oil Circuit (MPa)2.9
Fuel Tank (L)110
Hydraulic Tank (L)85
Engine Oil changes (L)5.3
Total transport length (mm)5850
Total transport width (mm)1880/1920
Total transport height (mm)2585
Counterweight ground clearance (mm)694
Minimum ground clearance (mm)369
Minimum turning radius of front working device (mm)2450
Back end turning radius (mm)1650
Track gauge (mm)1480/1500
Track plate width (mm)400
Track ground length (mm)1985/1990
Maximum digging radius (mm)6130
Maximum digging depth (mm)3830
Maximum excavation height (mm)5630
Maximum unloading height (mm)3945
Maximum vertical digging depth (mm)2680
Dodging plate width × height (mm)1880*365/1920*340
see more

Overview

No.977268

Brand Name:

XCMG

Model Number:

XE60

Year:

2018

Location:

Sichuan China
