Product Description
There is currently a second-hand XCMG XE75DA excavator, which was first put into use in October 2021. It is a local first-hand vehicle source, with a cumulative working time of approximately 3,000 hours (estimated). This device has won wide recognition in the market for its outstanding cost performance and excellent performance. In terms of power, this excavator is equipped with a well-known brand engine that has been tested in the market for a long time. The specific model is KUBOTA V3307-CR-TP, with a maximum output power of 45.5kW at 2200rpm, ensuring strong and stable driving force in various complex working conditions. Meanwhile, this engine also features excellent fuel economy and low emissions, meeting the requirements of national environmental protection standards. The hydraulic system is another highlight of this excavator. It adopts advanced negative flow control technology, combined with an efficient variable piston pump and high-quality hydraulic motor. This not only ensures smooth and precise operation but also significantly enhances the overall working efficiency and operational comfort of the machine. In addition, after strict testing and verification, its key components such as the main pump and distribution valve all
| Specifications | Value |
|---|---|
| No. | 977538 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7460 |
| Bucket capacity (m³) | 0.3 |
| Boom length (mm) | 3720 |
| Rod length (mm) | 1622 |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | V2607-DI-TE3B |
| Rated power (kw/rpm) | 42.4/2000 |
| Maximum torque (N.m) | 225.8 |
| Displacement (L) | 2.615 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 57 |
| Rod digging force (kN) | 38 |
| Maximum tractive force (kN) | 68.3 |
| Travel speed (km/h) | 5.4/2.9 |
| Maximum flow of main pump (l/min) | 160 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 18.6 |
| Working Hydraulic Circuit (Mpa) | 28 |
| Fuel Tank (L) | 130 |
| Hydraulic Tank (L) | 76 |
| Engine Oil changes (L) | 10 |
| Total transport length (mm) | 6150 |
| Total transport width (mm) | 2230 |
| Total transport height (mm) | 2685 |
| Counterweight ground clearance (mm) | 815 |
| Minimum ground clearance (mm) | 380 |
| Minimum turning radius of front working device (mm) | 1818 |
| Back end turning radius (mm) | 1800 |
| Track gauge (mm) | 1750 |
| Track plate width (mm) | 450 |
| Maximum digging radius (mm) | 6260 |
| Maximum digging depth (mm) | 4020 |
| Maximum excavation height (mm) | 7085 |
| Maximum unloading height (mm) | 5160 |
| Maximum vertical digging depth (mm) | 2920 |
