| Specifications | Value |
|---|---|
| No. | 963930 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
Description
【 Premium Recommendation 】2016 XCMG XE80 excavator, now available for just over 60,000 yuan! Since its manufacture, this excavator has accumulated a working time of only 3,500 hours, making it a rare low-usage device in the market. It is equipped with a highly efficient and energy-saving Cummins engine, which is powerful and has low fuel consumption. Even in complex and changeable construction environments, it can maintain stable output and ensure maximum operation efficiency. The hydraulic system adopts core components of the Kawasaki brand from Japan, featuring fast response speed and high control accuracy. It performs excellently in both excavation force and rotation speed, and can easily meet the demands of various earthwork projects. In addition, this machine is also equipped with a reinforced chassis structure and wear-resistant track plates, further enhancing the durability and off-road capability of the entire machine. The interior of the driver's cabin is spacious and comfortable, and is equipped with an air conditioning system, providing a good working environment for the operators. In conclusion, this XCMG XE80 excavator not only boasts outstanding performance and strong reliability, but also offers an extremely high cost-p
