| Specifications | Value |
|---|---|
| No. | 965797 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
Description
【 Premium Recommendation 】 XCMG XE380 excavator, meeting the 2024 National IV emission standards, only used for 2,000 hours, almost in brand new condition! This excavator is highly praised in the market for its outstanding performance and durability. It is equipped with an efficient and energy-saving power system, featuring a National IV engine that meets the latest environmental protection standards. Not only does it have strong power, but it also has high fuel efficiency, effectively reducing operating costs. The hydraulic system adopts advanced negative flow control technology, ensuring precise and smooth operation. It can handle tasks such as excavation, loading and crushing with ease. One of the highlights of this machine is its excellent maneuverability. Even first-time operators can quickly get the hang of it. The spacious and comfortable cab design offers a good field of vision and reduces fatigue from long hours of work. In addition, this XCMG XE380 is also equipped with a number of intelligent auxiliary functions, such as automatic idle speed and one-button start, which further enhance work efficiency and safety. Overall, this is a highly cost-effective choice for second-hand excavators, suitable for the needs of various me
