| Specifications | Value |
|---|---|
| No. | 966177 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
Description
"XCMG 80 Second-hand excavator This second-hand XCMG 80 excavator is one of the most popular small excavators in the market. It has not only won the favor of many users with its outstanding performance and durability, but also is highly competitive in price. Currently, its selling price is only 73,000 yuan. This excavator has a cumulative working time of approximately 2,500 hours. It is in good overall condition, properly maintained, has low mechanical wear and tear, and has a relatively long service life. In terms of the power system, this excavator is equipped with a high-quality diesel engine, which features strong power output and smooth operation performance. Even in harsh working environments, it can ensure efficient and stable operation. Meanwhile, the low fuel consumption design enables this excavator to effectively reduce operating costs during long-term operation. In terms of the hydraulic system, XCMG 80 adopts advanced hydraulic technology, ensuring precise control and rapid response during operation. Whether it's complex tasks such as digging, loading or crushing, they can all be handled with ease. In addition, its unique design has greatly enhanced work efficiency and reduced unnecessary downtime. We have prepared det
