2016 Caterpillar 307C
| Specifications | Value |
|---|---|
| No. | 961082 |
| Tonnage (tons) | 7 |
| Working weight (kg) | 7210 |
| Bucket capacity (m³) | 0.31 |
| Rod length (mm) | 1665 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Mitsubishi 4M40E1 |
| Rated power (kw/rpm) | 41/2200 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 95 x 100 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 2.84 |
| Working form | Meet US Tier2 and EU StageII emission requirements |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 50.6 |
| Rod digging force (kN) | 37.1 |
| Travel speed (km/h) | 3.3/5.2 |
| Maximum flow of main pump (l/min) | 64 x 2 |
| Traveling Hydraulic Circuit (Mpa) | 31.38 |
| Rotary Hydraulic Circuit (Mpa) | 19.61 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 27.46 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 90 x 932 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 998 |
| Fuel Tank (L) | 135 |
| Hydraulic Tank (L) | 57 |
| Engine Oil changes (L) | 11.2 |
| Coolant (L) | 15.5 |
| Hydraulic System (L) | 94(including fuel tank) |
| Total transport length (mm) | 6070 |
| Total transport width (mm) | 2290 |
| Total transport height (mm) | 2630 |
| Full cab height (mm) | 2630 |
| Counterweight ground clearance (mm) | 760 |
| Minimum ground clearance (mm) | 380 |
| Back end turning radius (mm) | 1750 |
| Total track length (mm) | 2760 |
| Track plate width (mm) | 450 |
| Total track width (mm) | 2290 |
| Maximum digging radius (mm) | 6340 |
| Maximum digging depth (mm) | 4110 |
| Maximum excavation height (mm) | 7290 |
| Maximum unloading height (mm) | 5150 |
| Maximum vertical digging depth (mm) | 3640 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 6200 |
Description
"Premium Second-hand Caterpillar 307C excavator This Caterpillar 307C mini excavator has been in use since 2015, with a total working time of 4,800 hours up to now, and its overall condition has remained excellent. In terms of appearance, the car body's paint is intact without any obvious dents or scratches. There is no sign of rust on the metal structural components either. The entire machine looks almost indistinguishable from a new car, which is very eye-catching. In terms of power, this excavator is equipped with an original imported C2.2 engine from Caterpillar. This engine is renowned for its powerful output and excellent fuel economy, ensuring stable performance even under long-term high-intensity operations. After professional testing, the engine is currently in good operating condition, starting quickly and running smoothly, fully meeting the daily construction requirements. The hydraulic system adopts Caterpillar's advanced negative flow control technology, ensuring smooth operation and sensitive response during the process. Whether it is excavation or loading, it can handle it with ease. In addition, all key components such as pumps and motors have undergone strict inspection and maintenance to ensure the efficient and st
Overview
No.961082
Brand Name：
CaterpillarModel Number：
307CYear：
2016
Location：
Guangdong China
