2016 Caterpillar 320C








| Specifications | Value |
|---|---|
| No. | 962048 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Description
【 Premium Recommendation 】 Second-hand Caterpillar 320C excavator, excellent condition, no-inspection quality, go directly to the construction site without additional investment, local test drive worry-free! This Caterpillar 320C is a highly sought-after medium-sized excavator in the market. With a total working time of only 6,000 hours, it is far shorter than the average service life of similar equipment, indicating that it is still in the best working condition. This machine is equipped with the original imported C7 engine from Caterpillar. This straight-six, turbocharged diesel engine is renowned for its powerful output and excellent fuel economy, with a maximum power output of 145 kilowatts, which is sufficient to meet the heavy-load operation requirements under various complex working conditions. Meanwhile, advanced electronic control injection technology ensures smooth engine operation and clean emissions, meeting the latest environmental protection standards. In terms of the hydraulic system, this machine is equipped with Caterpillar's unique combination design of high-pressure common rail pumps and variable piston pumps, which not only enhances the overall working efficiency of the machine but also significantly reduces energ
Overview
No.962048
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Guangdong China
