2021 Caterpillar 340DL
| Specifications | Value |
|---|---|
| No. | 969550 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38100-38600 |
| Bucket capacity (m³) | 1.88/2.14 |
| Boom length (mm) | 6500/6180 |
| Rod length (mm) | 2550/2800/3200 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 ACERT |
| Rated power (kw/rpm) | 209 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Bucket digging force (kN) | 176 |
| Rod digging force (kN) | 158 |
| Travel speed (km/h) | 5 |
| Maximum flow of main pump (l/min) | 2 x 280 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 310 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11200 |
| Total transport width (mm) | 3520 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3420 |
| Counterweight ground clearance (mm) | 1500 |
| Minimum ground clearance (mm) | 743 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5066 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3520 |
| Maximum digging depth (mm) | 7322 |
| Maximum excavation height (mm) | 10550 |
| Maximum unloading height (mm) | 7277 |
| Maximum vertical digging depth (mm) | 5712 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 11084 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 7035 |
Description
【 Premium Recommendation 】2021 Caterpillar 307 Ship excavator, with a working time of only 1,340 hours, features outstanding performance and reliable quality. This excavator is a star product specially designed by Caterpillar for water operations, and is particularly suitable for underwater engineering operations such as river dredging and lake silt removal. It not only has a powerful mining capability, but also features excellent stability and maneuverability, enabling it to easily handle various complex working environments. In terms of the power system, this machine is equipped with a highly efficient and energy-saving engine independently developed by Caterpillar, providing strong and stable power output. Even under harsh conditions, it can maintain good working efficiency. Meanwhile, the advanced fuel management system ensures lower fuel consumption and fewer emissions, meeting modern environmental protection requirements. The hydraulic system is a major highlight of this 307 ship excavator. It adopts Caterpillar's latest generation of intelligent hydraulic technology, featuring fast response speed, high control accuracy and easy maintenance. Whether it is precise operation or heavy-load work, it can complete the task with ease.
Overview
No.969550
Brand Name：
CaterpillarModel Number：
340DLYear：
2021
Location：
Fujian China
