2016 Caterpillar CT16
| Specifications | Value |
|---|---|
| No. | 967579 |
| Tonnage (tons) | 16 |
| Working weight (kg) | 17600 |
| Bucket capacity (m³) | 0.65 |
| Boom length (mm) | 5100 |
| Rod length (mm) | 2600 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.4 ACERT |
| Rated power (kw/rpm) | 89 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 105 x 127 |
| Displacement (L) | 4.4 |
| Working form | Meet EU Stage IIIB emission standards |
| Ground specific pressure (Kpa) | 49 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 111 |
| Rod digging force (kN) | 88 |
| Maximum tractive force (kN) | 156.2 |
| Travel speed (km/h) | 5.2 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 300 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 22.6 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Pilot pump flow (L/min) | 25.8 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 110 x 1039 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1331 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1193 |
| Fuel Tank (L) | 290 |
| Hydraulic Tank (L) | 106 |
| Engine Oil changes (L) | 13.5 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 190 |
| Total transport length (mm) | 8570 |
| Total transport width (mm) | 2520/2590/2690 (with different width tracks) |
| Total transport height (mm) | 3180 (to the top of the boom) |
| Full cab height (mm) | 2890 |
| Counterweight ground clearance (mm) | 1010 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2500 |
| Total track length (mm) | 3970 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500/600/700 |
| Total track width (mm) | 2520/2590/2690 |
| Maximum digging radius (mm) | 8910 |
| Maximum digging depth (mm) | 6090 |
| Maximum excavation height (mm) | 8920 |
| Maximum unloading height (mm) | 6280 |
| Maximum vertical digging depth (mm) | 4930 |
| Maximum excavation radius of stop surface (mm) | 8780 |
| Maximum effective digging depth (mm) | 5870 |
Description
【 Premium Recommendation 】 The top-quality Caterpillar 315C excavator, equipped with a 16-meter long arm, is the ideal choice for your construction projects! This machine not only has a well-maintained appearance and an extremely good condition, but more importantly, it boasts outstanding performance and an affordable price. It is definitely worth more than its price. 【 Basic Information - Brand Model: Caterpillar 315C - Working hours: It has only been running for about 4,000 hours and is in the best working condition. - Configuration highlights: It is specially equipped with a 16-meter long arm, suitable for various special operation environments such as deep pit excavation and river cleaning. "Power System It is equipped with an original imported Caterpillar engine, featuring strong power output and smooth operation characteristics. It can maintain efficient operation even under harsh conditions, has good fuel economy and low maintenance costs. "Hydraulic System Equipped with an advanced load-sensing hydraulic system, it can automatically adjust the oil pressure according to the actual load, ensuring smooth operation and energy conservation. Whether it is fine control or heavy excavation tasks, it can handle them with ease. 【 Add
Overview
No.967579
Brand Name：
CaterpillarModel Number：
CT16Year：
2016
Location：
Guangdong China
