2018 Doosan DX230LC-9C









| Specifications | Value |
|---|---|
| No. | 961950 |
| Tonnage (tons) | 22 |
| Working weight (kg) | 22020 |
| Bucket capacity (m³) | 1.2 |
| Boom length (mm) | 5700 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | DL06 |
| Rated power (kw/rpm) | 115/1900 |
| Cylinder diameter × stroke (mm) | 100*125 |
| Number of cylinders (PCS) | 6 |
| Ground specific pressure (Kpa) | 45 |
| Rotation speed (rpm) | 10.5 |
| Bucket digging force (kN) | 149 |
| Rod digging force (kN) | 105 |
| Travel speed (km/h) | 5.7/3.1 |
| Maximum flow of main pump (l/min) | 2*212 |
| Traveling Hydraulic Circuit (Mpa) | 34.3 |
| Rotary Hydraulic Circuit (Mpa) | 26.5 |
| Main pump type | Variable piston pump |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120*80*1060 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-135*95*1443 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-125*85*1263 |
| Fuel Tank (L) | 400 |
| Hydraulic Tank (L) | 195 |
| Engine Oil changes (L) | 27 |
| Total transport length (mm) | 9506 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 2950 |
| Full cab height (mm) | 2985 |
| Counterweight ground clearance (mm) | 1096 |
| Minimum ground clearance (mm) | 475 |
| Back end turning radius (mm) | 2794 |
| Total track length (mm) | 4440 |
| Track plate width (mm) | 600 |
| Number of sprockets (single side) (each) | 2 |
| Number of wheels (single side) (each) | 8 |
| Number of track plates (single side) (PCS) | 49 |
| Maximum digging radius (mm) | 9873 |
| Maximum digging depth (mm) | 6592 |
| Maximum excavation height (mm) | 9616 |
| Maximum unloading height (mm) | 6830 |
| Maximum vertical digging depth (mm) | 3929 |
| Maximum excavation radius of stop surface (mm) | 9699 |
Description
【 Premium Second-hand Excavator Recommendation 】 Doosan 230-9C from the end of 2018, a first-hand vehicle from the owner, is now on sale with sincerity! Since its commissioning at the end of 2018, this Doosan 230-9C excavator has been meticulously maintained by its original owner. Up to now, it has accumulated only about 3,500 hours of working time, making it a high-quality second-hand device with low working hours. This machine is equipped with a high-performance Cummins engine, which is powerful and fuel-efficient. It can handle complex terrains and high-intensity working environments with ease, ensuring construction efficiency while significantly reducing operating costs. Its advanced hydraulic system design ensures smooth and precise operation, making actions such as excavation and loading more fluid and effortless, reducing unnecessary energy loss and improving work efficiency. In addition, this excavator is equipped with a comfortable cab, which has a spacious interior and a wide field of vision. It is also equipped with an air conditioning system, providing the operator with a cool working environment even in the hot summer. More importantly, as it is the boss's own car, the vehicle maintenance records are complete. All repair
Overview
No.961950
Brand Name:
DoosanModel Number:
DX230LC-9CYear:
2018
Location:
Zhejiang China
