| Specifications | Value |
|---|---|
| No. | 969320 |
| Tonnage (tons) | 12 |
| Working weight (kg) | 12200 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4.6 |
| Rod length (mm) | 2.52 |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4BG1TC |
| Rated power (kw/rpm) | 66/2150 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.329 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 37 |
| Rotation speed (rpm) | 13.7 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 99 |
| Rod digging force (kN) | 65 |
| Travel speed (km/h) | 3.4/5.5 |
| Main overflow set pressure (Mpa) | 34.3 |
| Rotary hydraulic motor type | Quantitative plunger pump ×1 |
| Type of walking hydraulic motor | Variable piston pump ×2 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Variable piston pump ×2+ gear pump ×1 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 69(Full box 130) |
| Engine Oil changes (L) | 15.8 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2740 |
| Full cab height (mm) | 2740 |
| Counterweight ground clearance (mm) | 890 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2130 |
| Total track length (mm) | 3580 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 |
| Total track width (mm) | 2490 |
| Track ground length (mm) | 2880 |
| Maximum digging radius (mm) | 8270 |
| Maximum digging depth (mm) | 5570 |
| Maximum excavation height (mm) | 8570 |
| Maximum unloading height (mm) | 6160 |
| Maximum vertical digging depth (mm) | 5020 |
| Bulldozer lift or depth (mm) | No bulldozer |
Description
【 Premium Imported Hitachi 120-6 with imported gun Hammer 】 This second-hand Hitachi 120-6 excavator is a highly praised medium-sized excavator in the market. It not only inherits Hitachi's consistent high-quality manufacturing process, but also is equipped with original imported hammers, making its performance particularly outstanding in crushing operations. The overall working time of the machine is only 3,500 hours, which is in the golden period of mechanical service life. With stable performance and proper maintenance, it is very suitable for users who pursue efficient and durable equipment. In terms of the power system, this model is equipped with a well-tested original Hitachi engine, which features strong power output and smooth operation characteristics. Even under heavy load conditions, it can maintain good fuel economy and low emission standards, meeting the environmental protection requirements of modern construction. Meanwhile, the advanced electronic control system can automatically adjust the power output according to the actual load, ensuring the best working efficiency while extending the engine's lifespan. The hydraulic system adopts Hitachi's unique HIOS III technology, providing a more precise and smooth operation
