Product Description
Built for endurance, this 2022 XCMG XE80 demonstrates exceptional reliability with its robust 8-ton frame and proven Cummins B3.3 engine delivering 60kW of consistent power. Located in Zhejiang Wenzhou, this compact excavator combines Chinese engineering excellence with dependable performance across demanding jobsites.
Engineered as a proven workhorse, the XE80 features impressive digging capabilities with 53.6kN bucket force and 39.2kN rod force, while maintaining precise control through its advanced hydraulic system. The machine's compact 2.22m transport width and 1815mm turning radius ensure versatility in confined spaces without compromising operational strength.
- 8-ton working weight with 0.14-0.34m³ bucket capacity range
- Maximum digging depth: 4140mm, reach: 6375mm
- Toshiba variable pump system with 198L/min flow capacity
- 35° climbing ability with 34.2kPa ground pressure
- Water-cooled turbocharged engine with 127L fuel capacity
Representing four years of proven field performance, this XE80 showcases XCMG's commitment to building machines that endure. Ready for immediate deployment across construction, landscaping, and utility applications.
| Specifications | Value |
|---|---|
| No. | 983625 |
| Tonnage (tons) | 8 |
| Working weight (kg) | 7425 |
| Bucket capacity (m³) | 0.14-0.34 |
| Boom length (mm) | 3710 |
| Rod length (mm) | 1650 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Cummins B3.3 |
| Rated power (kw/rpm) | 60/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 3.3 |
| Working form | Water cooled/turbocharged |
| Ground specific pressure (Kpa) | 34.2 |
| Rotation speed (rpm) | 12 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 53.6 |
| Rod digging force (kN) | 39.2 |
| Travel speed (km/h) | 4.2/2.7 |
| Main overflow set pressure (Mpa) | 27.4 |
| Rotary hydraulic motor type | Plunger hydraulic motor |
| Type of walking hydraulic motor | Plunger hydraulic motor |
| Maximum flow of main pump (l/min) | 1*198+21 |
| Traveling Hydraulic Circuit (Mpa) | 27.4 |
| Rotary Hydraulic Circuit (Mpa) | 20.6 |
| Hydraulic crushing pipeline is standard | no |
| Main pump type | Toshiba variable pump ×1+ gear pump ×1 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Fuel Tank (L) | 127 |
| Hydraulic Tank (L) | 124 |
| Engine Oil changes (L) | 7 |
| Total transport length (mm) | 6155 |
| Total transport width (mm) | 2220 |
| Total transport height (mm) | 2610 |
| Counterweight ground clearance (mm) | 786 |
| Minimum ground clearance (mm) | 392 |
| Minimum turning radius of front working device (mm) | 1815 |
| Back end turning radius (mm) | 1770 |
| Track gauge (mm) | 1700 |
| Track plate width (mm) | 450 |
| Track ground length (mm) | 2119 |
| Maximum digging radius (mm) | 6375 |
| Maximum digging depth (mm) | 4140 |
| Maximum excavation height (mm) | 7167 |
| Maximum unloading height (mm) | 5100 |
| Maximum vertical digging depth (mm) | 3218 |
