2016 Caterpillar 320C








Product Description
【 Premium Recommendation 】 Second-hand Caterpillar 320C excavator, a cost-effective choice This second-hand Caterpillar 320C excavator has won the favor of many users with its outstanding performance and reliable quality. The working time is only XX hours (please consult for the specific usage hours). The overall condition is good and the maintenance is proper, ensuring the long-term stable operation of the equipment. In terms of the power system, this machine is equipped with an original Caterpillar C6.4 engine, with a maximum output power of up to 127kW. It not only provides strong power support but also has high fuel efficiency, effectively reducing operating costs. After professional testing, the engine runs smoothly without any abnormal noise or oil leakage, which proves that its maintenance condition is excellent. The hydraulic system is a major highlight of this machine. It is equipped with an efficient variable piston pump and a high-quality hydraulic motor, ensuring sensitivity and accuracy during operation. Whether it is excavation, loading or leveling operations, it can handle them with ease and perform outstandingly. Meanwhile, the reasonable layout design makes daily maintenance more convenient and further enhances the
| Specifications | Value |
|---|---|
| No. | 978198 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 21115 |
| Bucket capacity (m³) | 0.8 |
| Boom length (mm) | 5680 |
| Rod length (mm) | 2900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar CAT 3066 ATAAC |
| Rated power (kw/rpm) | 110/1800 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Displacement (L) | 6.4 |
| Ground specific pressure (Kpa) | 48.02 |
| Rotation speed (rpm) | 11.5 |
| Bucket digging force (kN) | 132 |
| Rod digging force (kN) | 99 |
| Travel speed (km/h) | 5.5 |
| Maximum flow of main pump (l/min) | 205 |
| Traveling Hydraulic Circuit (Mpa) | 34.4 |
| Rotary Hydraulic Circuit (Mpa) | 26 |
| Working Hydraulic Circuit (Mpa) | 34.3 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1030 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1430 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-120 x 1260 |
| Fuel Tank (L) | 320 |
| Hydraulic Tank (L) | 120 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 24 |
| Hydraulic System (L) | 200 |
| Total transport length (mm) | 9390 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3050 |
| Full cab height (mm) | 3050 |
| Minimum ground clearance (mm) | 460 |
| Back end turning radius (mm) | 2770 |
| Total track length (mm) | 4070 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2800 |
| Track ground length (mm) | 3260 |
| Maximum digging depth (mm) | 6550 |
| Maximum excavation height (mm) | 9440 |
| Maximum unloading height (mm) | 6770 |
| Maximum vertical digging depth (mm) | 5440 |
| Maximum excavation radius of stop surface (mm) | 9710 |
Overview
No.978198
Brand Name:
CaterpillarModel Number:
320CYear:
2016
Location:
Yunnan China
