Product Description
The Hitachi 360-3G excavator, after meticulous maintenance, has only single-digit processing records and is in excellent overall condition. The working time of this device is only a few thousand hours, which is far lower than the average usage time of similar models, ensuring its long-term stable operation capability. In terms of the power system, the Hitachi 360-3G is equipped with an efficient and reliable engine, which is expected to be an original Hitachi model. It has a strong output power and can meet the operation requirements under various complex working conditions. This engine not only features excellent fuel economy but also adopts advanced emission control technology, meeting strict environmental protection standards. This enables the equipment to maintain high performance while minimizing its impact on the environment. The hydraulic system is a major highlight of the Hitachi 360-3G. It adopts a combination of high-performance hydraulic pumps and hydraulic motors, providing a smooth and precise operating experience. This system ensures the smoothness and response speed of actions such as excavation and loading, greatly enhancing work efficiency. In addition, its intelligent control system can automatically adjust the oil
| Specifications | Value |
|---|---|
| No. | 978118 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
