Product Description
There is currently a second-hand Hitachi 60-6 ash valve excavator with a total usage time of only over 30,000 hours, in good condition. This equipment is equipped with high-performance original imported engines, which are expected to be the well-tested Hitachi SAA6D102E-1 engine. It features strong power, stable and reliable operation, and can meet the operational requirements under various complex working conditions. In terms of the hydraulic system, it is equipped with an advanced variable piston pump and an efficient hydraulic motor combination, ensuring smooth operation and rapid response of the entire machine when performing tasks such as excavation and loading, while also having good fuel economy. As a compact excavator, the Hitachi 60-6 not only boasts excellent flexibility and mobility but is also particularly suitable for operations in narrow urban Spaces. Its unique grey valve design effectively enhances work efficiency and reduces maintenance costs. In addition, the sturdy and durable structural components as well as the humanized layout of the cab also provide the operator with a comfortable and safe working environment. In conclusion, this is a high-quality second-hand construction machinery with an extremely high cost pe
| Specifications | Value |
|---|---|
| No. | 978333 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
