Product Description
We are selling a second-hand 360-type excavator with outstanding performance. The total working time is only 360 hours, ensuring that the equipment is in excellent working condition. This excavator is equipped with an efficient and reliable engine, the industry-leading ISUZU AH-6HK1X, with a maximum output power of 270kW, which can easily meet the high-load operation requirements under various complex working conditions. The powerful power system not only ensures the stable operation of the machine, but also significantly improves work efficiency. In terms of the hydraulic system, this machine adopts the advanced Kawasaki KPM series main pump combined with the matching high-performance motor, ensuring smooth operation and accuracy. This meticulously designed and optimized hydraulic configuration makes the operation more sensitive and accurate, enabling tasks such as excavation, loading, and crushing to be accomplished with ease. In addition, this excavator also has the following obvious advantages: - Strong adaptability: Suitable for construction projects under various terrain conditions; - High efficiency and energy saving: Equipped with an intelligent control system, it effectively reduces fuel consumption. - Comfort and Safety: Th
| Specifications | Value |
|---|---|
| No. | 978384 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5850 |
| Bucket capacity (m³) | 0.22 |
| Boom length (mm) | 3.49 |
| Rod length (mm) | 1.6(Enhanced version) |
| Country of origin | Hefei, Anhui Province |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | ISUZU CC-4JG1 |
| Rated power (kw/rpm) | 40.5/2100 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.059 |
| Working form | Direct injection |
| Ground specific pressure (Kpa) | 33 |
| Rotation speed (rpm) | 9.3 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 41.4 |
| Rod digging force (kN) | 28.4 |
| Travel speed (km/h) | 2.5/4.5 |
| Main overflow set pressure (Mpa) | 24.5 |
| Rotary hydraulic motor type | Axial piston motor ×1 |
| Type of walking hydraulic motor | Variable swash plate plunger motor ×2 |
| Main pump type | Variable piston pump ×2+ gear pump ×2 |
| Fuel Tank (L) | 120 |
| Hydraulic Tank (L) | 61(Full box 95) |
| Engine Oil changes (L) | 12 |
| Total transport length (mm) | 6060 |
| Total transport width (mm) | 2060 |
| Total transport height (mm) | 2470 |
| Full cab height (mm) | 2470 |
| Counterweight ground clearance (mm) | 620 |
| Minimum ground clearance (mm) | 310 |
| Minimum turning radius of front working device (mm) | 2510 |
| Back end turning radius (mm) | 1650 |
| Total track length (mm) | 2480 |
| Track gauge (mm) | 1600 |
| Track plate width (mm) | 400 |
| Total track width (mm) | 2000 |
| Track ground length (mm) | 2000 |
| Maximum digging radius (mm) | 6250 |
| Maximum digging depth (mm) | 3850 |
| Maximum excavation height (mm) | 5800 |
| Maximum unloading height (mm) | 4080 |
| Maximum vertical digging depth (mm) | 3300 |
| Bulldozer lift or depth (mm) | 430/400 |
