Product Description
We are selling a top-quality second-hand XCMG XE60 excavator. This equipment has a short working time, with only 1,500 hours of usage, and is in the best condition for use. The power system is equipped with the high-performance Yanmar 4TNV98 engine, with a maximum power output of up to 36.4 kilowatts, ensuring strong power output and excellent fuel economy. In terms of the hydraulic system, it is equipped with high-quality variable piston pumps and low-speed high-torque hydraulic motors, providing efficient and stable operational performance. Whether it is excavation, loading or crushing operations, it can handle them with ease. This XCMG XE60 excavator is specially equipped with an advanced hydraulic quick connection device, which supports the rapid replacement of various attachments and greatly improves work efficiency. In addition, it is equipped with a small digging bucket, which is very suitable for fine operations in narrow urban Spaces. At the same time, it can also be optionally equipped with a breaker, further expanding its application range. Local stock supply. Welcome those interested to contact us privately for detailed inquiries. We will provide you with the best service and the most competitive prices. This is not only a
| Specifications | Value |
|---|---|
| No. | 978253 |
| Tonnage (tons) | 6 |
| Working weight (kg) | 5960 |
| Bucket capacity (m³) | 0.09-0.23 |
| Boom length (mm) | 3000 |
| Rod length (mm) | 1600 |
| Country of origin | Xuzhou |
| power | Traditional power |
| manufacturer | Made in China |
| bucket | backhoe |
| Engine type | Yanmar 4TNV94L |
| Rated power (kw/rpm) | 39.8/2200 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 3.054 |
| Ground specific pressure (Kpa) | 32.1 |
| Rotation speed (rpm) | 9.5 |
| Climbing ability (%) | 35 ° |
| Bucket digging force (kN) | 42.5 |
| Rod digging force (kN) | 28.5 |
| Travel speed (km/h) | 4.2/2.2 |
| Main overflow set pressure (Mpa) | 22 |
| Maximum flow of main pump (l/min) | 2*60.5+40.3+9.9 |
| Traveling Hydraulic Circuit (Mpa) | 22 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Hydraulic crushing pipeline is standard | is |
| Main pump type | Rexroth |
| Pilot Oil Circuit (MPa) | 2.9 |
| Fuel Tank (L) | 110 |
| Hydraulic Tank (L) | 85 |
| Engine Oil changes (L) | 5.3 |
| Total transport length (mm) | 5850 |
| Total transport width (mm) | 1880/1920 |
| Total transport height (mm) | 2585 |
| Counterweight ground clearance (mm) | 694 |
| Minimum ground clearance (mm) | 369 |
| Minimum turning radius of front working device (mm) | 2450 |
| Back end turning radius (mm) | 1650 |
| Track gauge (mm) | 1480/1500 |
| Track plate width (mm) | 400 |
| Track ground length (mm) | 1985/1990 |
| Maximum digging radius (mm) | 6130 |
| Maximum digging depth (mm) | 3830 |
| Maximum excavation height (mm) | 5630 |
| Maximum unloading height (mm) | 3945 |
| Maximum vertical digging depth (mm) | 2680 |
| Dodging plate width × height (mm) | 1880*365/1920*340 |
